Z-EFG-80-200 Electric Gripper Adjustable Hand Gripper

The Z-EFG-80-200 Electric Hand Gripper is designed for high precision, fast response, and compact integration in various industrial automation applications. Below is an overview of the features, specifications, and benefits of this gripper:
Key Features:

• Adjustable Stroke and Clamping Force: The hand gripper features an 80mm adjustable stroke with a clamping force range from 80N to 200N. This adjustability allows the gripper to handle different sizes and types of objects effectively.
• Mechanical Self-locking: One of the standout features is its mechanical self-locking function, ensuring the gripper holds its position even after power is turned off, preventing any unwanted drop-down of the clamped object.
• Fast Operation: With a shortest stroke time of 0.8 seconds, this electric gripper is faster than traditional air grippers, making it suitable for high-speed production lines.
• High Precision: The gripper offers repeatability of ±0.02mm, ensuring highly accurate clamping with minimal variation.
• Compact Design: The overall size of the gripper is 150mm x 50mm x 172mm, making it easy to integrate into compact spaces. The built-in controller further reduces the footprint, simplifying installation and reducing the need for additional components.
• Long Life Span: The gripper is designed for durability, capable of enduring tens of millions of cycles while maintaining high performance.
• Versatile Control: The hand gripper supports multiple control methods including 485 (Modbus RTU), Pulse, and V/O, making it compatible with most PLC systems for easy integration.

Specifications:

• Total Stroke: 80mm (adjustable)
  Clamping Force: 80-200N (adjustable)
  Repeatability: ±0.02mm
  Clamping Weight Capacity: Up to 2kg
  Transmission Mode: Screw rod + Timing belt + Ball guide
  Shortest Stroke Time: 0.8s
  Movement Type: Two-finger parallel movement
  Weight: 2kg
  Dimensions: 150mm x 50mm x 172mm
  Work Voltage: DC 24V ±10%
  Rated Current: 1A
  Peak Current: 8A
  Power: 30W
  IP Protection Grade: IP20
  Motor Type: DC Brushless motor
  Operating Temperature Range: 5~55°C
  Operating Humidity Range: 35%~80% RH (Non-frost)

Advantages:

• Compact and Integrated Design: The built-in controller and compact structure make this electric gripper easy to integrate into production lines with limited space.
• High Performance: With fast stroke time, high repeatability, and adjustable clamping force, it is suited for demanding tasks in industrial automation.
• Flexible Clamping: The tail of the gripper is interchangeable, allowing for customization based on the clamping objects, ensuring versatility in handling different types of workpieces.
• Low Maintenance: The dynamic components require oil supplementation every 6 months or after tens of millions of cycles, ensuring reliability and longevity.

In summary, the Z-EFG-80-200 Electric Hand Gripper is an advanced solution for automation that combines high clamping force, fast operation, and compact integration. It is well-suited for industries requiring precision, speed, and reliability in clamping applications.
